Current: 10A
Voltage: 6V
Power: 60W
Channel: 10CH
CC Mode
Range: 0~10A
Setting Resolution: 167μA
Setting Accuracy: 0.05%+0.05%F.S
CV Mode
Range: 6V
Setting Resolution: 0.1mV
Setting Accuracy: 0.05%+0.05%F.S
Internal Resistance Measurement
Range 0
Output range: 0~100mV
Resolution: 50μV
Accuracy: 0.1%+0.1%F.S
Range 1
Output range: 0~50mV
Resolution: 25μV
Accuracy: 0.1%+0.1%F.S
Range 2
Output range: 0~30mV
Resolution: 15μV
Accuracy: 0.1%+0.1%F.S
Range 3
Output range: 0~15mV
Resolution: 7.5μV
Accuracy: 0.1%+0.1%F.S
Current Measurement
Range: 0~10A
Readback Resolution: 24 bits
Readback Accuracy: 0.05%+0.05%F.S.
Voltage Measurement
Range: 0~6V
Readback Resolution: 24 bits
Readback Accuracy: 0.02%+0.02%F.S.
Operating Temperature: -10℃-40℃
Relative Humidity: 5%-90%
AC Input: 220V AC±10%, frequency 47Hz-63Hz
Net Weight: Approx. 13.5kg
Dimension: 3U, 132.5(H)*482.6(W)*360(D)mm
