NGI N62402-40-400 Low Voltage High Current DC Electronic Load (2kW, 400V, 2000A)

Voltage: 40V

Current: 400A

Power: 2000W

Min operating voltage: 0.1V@200A/ 0.2V@400A

CC mode

Range: 0~40A/ 0~400A

Setting Resolution: 1mA/ 10mA

Setting Accuracy (23±5℃): Low range: 0.1%+0.1%F.S., High range: 0.1%+0.15%F.S.

CV mode

Range: 0~4V/ 0~40V

Setting Resolution: 0.1mV/ 1mV

Setting Accuracy: (23±5℃) 0.05%+0.05%F.S.

CP mode

Range: 0~2000W

Setting Resolution: 0.1W

Setting Accuracy (23±5℃): 0.5%+1%F.S

CR mode

Range: 0.002Ω~10Ω / 0.04Ω~100Ω

Setting Resolution: 16 bits

Setting Accuracy (23±5℃): 0.35%+0.312S / 0.35%+31.2mS

Slew Rate

Current: 6.6~400A/ms / 400~2000A/ms

Voltage: 0.334~16.7V/ms / 16.7~166.7V/ms

Power: 6.6~400A/ms / 400~2000A/ms

Resistance: 6.6~400A/ms / 400~2000A/ms

Voltage Measurement

Range: 0~4V/ 0~40V

Readback Accuracy (23±5℃): 0.05%+0.05%F.S.

Current Measurement

Range: 0~40A / 0~400A

Readback Accuracy (23±5℃):0.1%+0.1%F.S.

Power Measurement

Range: 0~2000W

Readback Accuracy (23±5℃): 0.5%+1%F.S.

Dynamic Mode

T1& T2: 1~60000ms

Resolution: 1ms

Accuracy: 1ms+100ppm

Interface: LAN/RS232/CAN

AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz

Sampling Frequency: 25Hz

Communication Response Time: ≤10ms

Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃

Net weight: Approx. 24kg

Dimension: 12U, 530.0(H)*482.0(W)with handle*612.0(D)mm
