Voltage: 0~80V
Current: 0~360A
Power: 9000W
CV Mode
Range: 0~80V
Setting Resolution: 1mV
Setting Accuracy (23±5℃): 0.05%+0.05%F.S
CC Mode
Range: 0~360A
Setting Resolution: 10mA
Setting Accuracy ( 23±5℃): 0.1%+0.1%F.S
Voltage measurement
Range: 0~80V
Readback Resolution: 1mV
Readback Accuracy ( 23±5℃): 0.05%+0.05%F.S
Temperature Coefficient: 50ppm/℃
Current Measurement
Range: 0~360A
Readback Resolution: 10mA
Readback Accuracy ( 23±5℃): 0.1%+0.1%F.S
Temperature Coefficient: 50ppm/℃
Line Regulation
Voltage: ≤0.01%
Current: ≤0.05%
Load Regulation
Voltage: ≤0.05%
Current: ≤0.05%
Output Ripple(20Hz-20MHz)
Voltage Ripple (p-p): ≤400mVp-p
Efficiency: 90%（Typical）
Interface: RS232/LAN
Communication Response Time: ≤5ms
AC Input: Single phase, 380V AC±10%, current ≤16A, frequency 47Hz~63Hz
Temperature: Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 54kg
Dimension: 6U, 264.0(H)*482.0(W)with handle*600.0/580.0(D)mm
