Rated output power: 250VA
Maximum output power with respect to products: 313VA
Rated output current::
+ DC mode: ± 1.9A
+ AC mode(rms): 2.1Arms
Peak current: 2.5 X rated value (rms)
Rated output voltage: 120Vrms (± 170V) sinewave
Maximum output voltage: 141Vrms (± 200V) sinewave
Gain:
+ CV: 100V/V
+ CC: 1.5A/V
Gain stability: ± 100ppm (typ.), ± 100ppm/8h (typ.) (CV, DC to 1kHz)
Output mode: CV, CC, DC and AC
Load regulation (DC mode): CV mode : Within ± 0.1% (DC to 1kHz), ± 2% max. (1kHz to 20kHz); CC mode : Within ± 2% (DC to 1kHz), ± 20% max. (1kHz to 20kHz)
Line regulation (DC mode): CV mode : Within ± 0.1% (DC to 1kHz), ± 1% max. (1kHz to 20kHz)
Frequency response: +0.2, -0.5dB : DC to 5kHz (45Hz to 5kHz for AC mode), +0, -3dB : 5kHz to 20kHz
Harmonic distortion (DC mode): CV mode : 0.05% or less (10Hz to 1kHz), 1% or less (10kHz), 2.5% or less (20kHz); CC mode : 0.5% or less (10Hz to 1kHz), 2.5% or less (20kHz)
Output offset voltage/current: Adjustable to zero
Remote sensing: Possible in the CV and DC mode (DC to 1kHz)
Output type: Balanced , single-ended possibly, isolated between input and output
Power requirements: 1φ 100V ± 10% (120, 200, 220 or 240V is available as option.) 48Hz to 62Hz
Dimensions(mm): 430(W) X 176(H) X 598(D)
Weight: approx. 27kg
