Width: 1.35 mm
Height: 1 mm
Length: 2.25 mm
Function: XOR
Logic Type: 2-Input OR
Unit Weight: 6 mg
Logic Family: HC
Logic Function: XOR
Mounting Style: SMD/SMT
Number of Gates: 1 Gate
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Propagation Delay Time: 23 ns
Low Level Output Current: 2.6 mA
Operating Supply Voltage: 5 V
High Level Output Current: - 2.6 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
