Width: 1 mm
Height: 0.46 mm
Length: 1.45 mm
Function: OR
Logic Type: CMOS
Logic Family: AUP
Logic Function: OR
Mounting Style: SMD/SMT
Output Current: 20 mA
Output Voltage: 3.6 V
Number of Gates: 1 Gate
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 800 mV
Number of Input Lines: 3 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 250 mW
Propagation Delay Time: 4.2 ns
Low Level Output Current: 4 mA
Operating Supply Voltage: 1.8 V, 2.5 V, 3.3 V
High Level Output Current: - 4 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
