Image Sensor: 1280×800 (MP) CMOS
Light Source: Red LED/White LED
Barcodes: 1D; 2D; Postal; OCR
Resolution: ≥3mil
Depth of Field: EAN-13: 55mm-570mm (13mil). Code 39: 115mm-170mm (5mil). PDF 417: 85mm-225mm (6.7mil). Data Matrix: 65mm-305mm (10mil). QR Code: 25mm-395mm (15mil)
Scan Angle: Pitch: ±55°, Roll: 360°, Skew: ±55°
Field of View: Horizontal 39°, Vertical 24°
Minimum Symbol Contrast: 25%
Aiming Light: Blue LED
Connectivity: RS-232, USB
Operating Voltage: 5VDC±5%
Rated Power Consumption: 1289.6mW (typical)
Current@5VDC: Operating: 241.2mA (typical), 260.5mA (max). Standby: 71.3mA
Dimensions (L×W×H): 159.0×113.5×73.3mm
Weight: 162g
Notification: Beeper, LED
Operating Temperature: -20°C to 60°C
Storage Temperature: -40°C to 70°C
Humidity: 5%~95% (non-condensing)
ESD: ±15 KV (air discharge); ±8 KV (contact discharge)
Drop Resistance: 1.5m drop to concrete
Protection Standard: IP42
