Image Sensor: 640×480 CMOS
Light Source: White LED
Barcode Reading: 1D; 2D
Resolution: ≥3mil
Depth of Field: EAN-13: 50mm-260mm (13mil), Code 39: 50mm-115mm (5mil), PDF 417: 50mm-120mm (6.7mil). Data Matrix: 35mm-125mm (10mil). QR Code: 30mm-170mm (15mil).
Scan Angle: Pitch: ±55°; Skew: ±55°; Roll: 360°
Field of View: Horizontal 45°, Vertical 34°
Minimum Symbol Contrast: 20%
Aiming: Red LED (625nm)
Connectivity: RS-232, USB
Operating Voltage: 5VDC±5%
Rated Power Consumption: 950mW (typical)
Current@5VDC: Operating: 190mA (typical), 201mA (max); Standby: 35mA
Dimensions: 145×101×68mm
Weight: 111g
Notification: Beeper, LED
Operating Temperature: -20°C to 60°C
Storage Temperature: -40°C to 70°C
Humidity: 5%~95% (non-condensing)
ESD: ±15 KV (air discharge); ±8 KV (direct discharge)
Drop Resistance: 1.2m
Protection Standard: IP42
