Input: 250W, 110V±10% or 220V±10%, Single Phase, 50Hz/60Hz
Output:
Voltage: 0.7V ~ 5V, ±1mV
Current:
0.1uA – 150uA, ±30nA
150uA – 5mA, ±1uA
5mA- 150mA, ± 30uA
150mA – 5A, ±1mA
Resolution: AD 16bit, DA 16bit
Data Acquisition:
Frequency: 1000Hz Max
Mode:
Min Time Interval: 1ms
Min Voltage Interval: 1mV
Min Current Interval: 100nA
Response Time 100usec, 10%-90% Current Range
Operation Mode:
Charge: Constant Current, Constant Voltage, Constant Resistance
Discharge: Constant Current, Constant Power, Constant Resistance
Simulation: Constant Current, Constant Power, Minimum Pulse Width: 400us.
End Conditions: Voltage, Current, Time, Capacity, Energy, -δV
Channel Control: Independent
Step Editor:
Cycles: Max 65535
Steps: Max 255
Loops: Max 4 nested loops
Step Time Format: 00:00:00.000 (mm:hh:ss.ms)
Input Impedance: ≥500MΩ
Noise: <75dB
Environment:
Operating: 15℃~40℃, ≤70% RH, No Condensation
Storage: -10℃~50℃, ≤80% RH, No Condensation
Battery Holders Options: Coin Cell Holders, Alligator Clips, Ring Terminal
Dimensions: 443*615*125 (W*D*H mm)
