Nagman DPC 3000 Precision pressure controller

Control range: From vacuum up to 210 bar

Control accuracy: 0.005% FS

Measuring ranges:

+ 0.3% rgd + 0.3% FS; -2.5 mbar to +2.5 mbar

+ 0.2% rgd + 0.2% FS; 0…50 mbar, 0…100 mbar

+ 0.04% rgd + 0.04% FS; 0…400 mbar, 1 000 mbar

+ 0.025% rgd + 0.025% FS; 0…1 bar, 0…10 bar, 0…20 bar, 0…35 bar, 0…70 bar, 0…100 bar, 0…150 bar, 0…200 bar, 0…210 bar

+ 0.01% FS; 0…1.3 bara, 0…3,5 bara, 0…10 bara, 0…25 bara, 0…50 bara

Media: Gases, low viscosity liquids

Interfaces: RS232, USB, LAN

Electronic connection: Rubber connector

Supply voltage: 100…240 VAC, 50/60 Hz

Pressure connection: G 1/8” I with exchangeable fine mesh filter 5μ

Special features: 8-pole connector strip for external control functions (optional), customer-specific

Dimensions: 130 x 380 x 265 mm (H x W x D)

Weight: 4 700 g
