Ranges: 0 to 70 / 100 / 200 / 400 / 600 / 700 Bar
Accuracy: ±0.02% F.S.
Temperature Compensation: 0 to 50°C (Automatic)
Resolution: Minimum 5 digits
Display: Graphic
Engineering Units: Kg/cm2, Bar, mBar, PSI, mH2O, mmH2O, cmH2O, inH2O, ftH2O, mmHg, inHg, Atm, Mpa, Kpa, Pa
mA Input:
+ 50mA (Active Loop) & 25mA (Passive Loop)
+ Load Resistance : 800Ω
Volt Input: 0 to 30V DC
Resolution (mA / V): 0.001
Pressure Switch Test: Maximum 5V DC (approx.)
Over Pressure Alarm: 120% FS (Audio / Visual)
Battery: Rechargeable Battery & Charger
Low Battery Indication: Provided
Instrument Dimension: 260 x 130 x 105 (L x B x H)
Instrument Weight: 1.5 Kg
-Standard Delivery:
Pressure Indicator with matching Hand Pump
Set of Adaptors (BSP & NPT)
Test Leads & Seals Kit
Hose with End Fittings
External Battery Charger
RS-232 Computer Interface
Carrying Case
Calibration Certificate from NABL Accredited – as per ISO/IEC 17025:2005 Laboratory
Instruction Manual
-Optionals:
“Calpress” Calibration Software
*Panel Mounted Model with External Pressure Module(s)
Internal Sensor Ranges & Other Specifications (as in Bench-top Models)
EPM Ranges:
+ Pneumatic -0.85 to 2 / 7 / 10 / 20 / 35 / 40 Bar
+ Hydraulic: 0 to 70 / 100 / 200 / 400 / 600 / 700 Bar
EPMs: 2 / 3 / 4
Accuracies: ±0.05% F.S. / ±0.025% F.S.
Mounting: Panel Mounted (19” Rack Size)
Dimensions: 350 x 185 x 178 mm (L x B x H) – Typical for 3 EPMs
