Width: 27.81 mm (1.095 in)
Height: 9.88 mm (0.389 in)
Length: 45.47 mm (1.79 in)
Industry: Medical, Industrial
Dimensions: 45.47 mm x 27.81 mm x 9.88 mm
Efficiency: 82 %
Application: Industrial, Medical
Unit Weight: 12 g
Output Power: 6 W
Input Voltage: 18 V to 36 V
Mounting Style: Through Hole
Mechanical Style: Isolated
Isolation Voltage: 5.7 kV
Number of Outputs: 2 Output
Moisture Sensitive: Yes
Input Voltage - Max: 36 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 240 mA
Output Current-Channel 2: 240 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 10 V
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
