Width: 10.9 mm (0.429 in)
Height: 28.1 mm (1.106 in)
Length: 38.9 mm (1.531 in)
Industry: Medical, Industrial
Dimensions: 38.89 mm x 28.12 mm x 10.9 mm
Efficiency: 80.5 %
Application: Industrial, Medical
Unit Weight: 12 g
Output Power: 6 W
Input Voltage: 9 V to 18 V
Mounting Style: Through Hole
Mechanical Style: Isolated
Isolation Voltage: 5.7 kV
Number of Outputs: 2 Output
Moisture Sensitive: Yes
Input Voltage - Max: 18 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 240 mA
Output Current-Channel 2: 240 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 10 V
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
