Width: 6.15 mm (0.242 in)
Height: 10.15 mm (0.4 in)
Length: 19.65 mm (0.774 in)
Industry: Medical, Industrial
Application: Industrial
Unit Weight: 1.600 g
Output Power: 1 W
Input Voltage: 22.8 V to 25.2 V
Mounting Style: Through Hole
Isolation Voltage: 3.5 kV
Number of Outputs: 1 Output
Input Voltage - Max: 25.2 V
Input Voltage - Min: 22.8 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 200 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
