Width: 0.8 mm
Height: 0.8 mm
Length: 1.6 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 5 %
Inductance: 390 nH
Application: Automotive
Termination: Standard
Unit Weight: 4 mg
Qualification: AEC-Q200
Mounting Style: PCB Mount
Termination Style: SMD/SMT
Maximum DC Current: 620 mA
Maximum DC Resistance: 280 mOhms
Self Resonant Frequency: 570 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
