Measuring Range
Voltage Measuring Range: 0-60V 1mV Accuracy: ±5mV
Internal Resistance Measuring Range :0-1999mΩ Resolution 1mΩ
Capacity Measuring Range: 0-99999mAH Minimum Resolution
R1 R2 Resistance: 1kΩ~200kΩ
Measuring Accuracy
Voltage Measuring Accuracy: ±(Result*%0,1+3mV) (Voltage 0~36V); ±(Result*%0,1+30mV) (Voltage 37~60V)
Current Measuring Accuracy: ±(Result*%0,2+30mA) (Current 0~10A); ±(Result*%0,5+30mA) (Available11~30A)
Internal Resistance Measuring Accuracy: ±(Result*1%+1mΩ)
Capacity Measuring Accuracy: ±2%
Test Speed :Static Test (All Functions) 1.1-2 s
Dahili CNC: Maksimum Output Voltageı (sabit Voltage + sabit 30V
Voltage Source Index:
Output Maksimum Current: 1A (0.1mA ~ 3.0000A)
Output Maksimum Power: 30W
Ripple Voltage: <20mV
Load Regulation: <10%
Boost Response Time: 1s
Internal CNC Electronic Load Index:
Maximum Discharge Voltage: 60V
Maximum Discharge Current :3A Constant (0.1mA ~ 3.000A)
Limit Power: 100W (Constant)
Load Model: Constant Voltage Constant Current
Communication : Yes (with host computer software)
