Testing Range:
Voltage Measuring Range: 0-62V; Resolution: 1mV; Accuracy: ±5mV
Internal Resistance; Measurement Range: 0-1999mΩ; Resolution1mΩ
Capacity Measurement Range: 0-99999mAH, Minimum Resolution 1mAH
R1 R2 Resistance : 1kΩ~200kΩ
Accuracy:
Voltage Measuring Range: ±(Result*%0.1+3mV)(Voltage 0~36V); ±(Result*0.1%+30mV)(Voltage 37~60V)
Current Measuring Range : ±(Result*%0.2+30mA)(Current 0~10A); ±(Result*0.5%+30mA)(Current 11~30A)
Dahili Resistance Measuring : ±(Result*1%+1mΩ)
Capacity Measurement Accuracy: ±2%
Test Speed:
Static Test (All Functions): 1.1-2s
Capacity Test : Determine the capacity test time according to the battery capacity and discharge power
