MULTI MIS-1A Analog Insulation Resistance Tester (50V-10MΩ,125V-20MΩ,250V-50MΩ)

Rated voltage and effective measuring range: 50V-10MΩ,125V-20MΩ,250V-50MΩ

Center scale: 0.2MΩ/0.5MΩ/1MΩ

Minimum measurable resistance at rated voltage: 0.05MΩ,0.125MΩ,0.25MΩ

Rated current: 1mA+20%-0%

Open circuit voltage: Rated voltage+30%-0%

Short circuit current: <2mA

Withstanding Voltage: AC 3700V, 1 minute (Between input terminal and outer case)

Storage Temperature: -10℃～60℃, 80% RH max (Without condensation)

Operating Temperature: 0℃ to 40℃, 80% RH max. (Without condensation)

Power supply: 1.5V (AM-3, R6 or "AA" size)×6

Weight: Approx. 330g (Excluding batteries)

Accuracy(DC 50V):

First effective range：0.01MΩ～5MΩ ±5%rdg、10MΩ～50MΩ ±30%rdg

Accuracy(DC 125V):

First effective range：0.02MΩ～10MΩ ±5%rdg

Second effective range：0.01MΩ～0.02MΩ 10MΩ～20MΩ ±10%rdg,10MΩ～100MΩ ±30%rdg

Accuracy(DC 250V):

First effective range：0.05MΩ～20MΩ ±5%rdg

Second effective range：0.02MΩ～0.05MΩ 20MΩ～50MΩ ±10%rdg,50MΩ～100MΩ ±30%rdg

Accuracy(DC 500V):

First effective range：0.1MΩ～50MΩ ±5%rdg

Second effective range：0.05MΩ～0.1MΩ 50MΩ～100MΩ ±10%rdg

Accuracy (DC 1000V):

First effective range：2MΩ～1000MΩ ±5%rdg

Second effective range：1MΩ～2MΩ 1000MΩ～2000MΩ ±10%rdg

AC voltage (50/60Hz):

Range/Accuracy/Input impedance/Maximum input voltage

AC 600V/±2.5% of full scale/Approx. 1.5M/AC 600V rms
