Range/ Resolution/ Accuracy:
3mA/0.001mA/±1%rdg ±5dgt
30mA/0.01mA/±1%rdg ±5dgt
300mA/0.1mA/±1%rdg ±5dgt
20A/0.01A/±1%rdg ±5dgt
CT inside diameter: 35mm
Measuring frequency: 50 ~ 60Hz
Applicable circuit voltage: AC600V
Withstanding voltage: AC3.7kV/1min
Operating Temperature and Humidity Range: 0～40℃ less than 80%RH (without condensation)
Storage Temperature and Humidity Range: -10～60℃ less than 70%RH (without condensation)
Power supply: LR03*3ea
Dimensions: 217*86*Φ55mm
Weight: 410g
