INPUTS:
Differenal Input: Stac discharge protected
Input Connecon : Differenal with shield connected to case, MS3101E-10SL-3P
Input Impedance : 10Ω maximum
Maximum Input Charge : 20,000 pC pk, maximum
Velocity Output Rear: Panel BNC female connector
Acceleraon Output (buffered) : Front Panel BNC female connector
Output Impedance 1: 0Ω maximum
Capacitance Load : 0.1μF maximum
DC Output Bias: 0 Vdc
Linear Output Voltage : 17Vpk-pk max
Output Current : 25 mA maximum
Linearity : 0.02
Residual Noise (RTD) : 1.0 mV RMS maximum at gain =1, 4.0 mV RMS max at gain = 10
CONFIGURATION OPTIONS:
Number of Channels: 4, 6, 8
Channel Gain Sengs: 1, 4, 10 mV/pC
High-pass Filter Opons: 10, 15, 20, 25 Hz
Outputs (ACC & VEL): Differenal or Single Ended
POWER REQUIREMENTS
AC Power Requirements 110/240 VAC ±15% 50 - 400 Hz
Warm-up Time 5 minutes
PHYSICAL CHARACTERISTICS
Dimensions 3.5” h X 19” w X 13” d
Weight 11.7 lbs
