Impulse Mode:
Voltage range in kV: 0-4 / 0 - 8 / 0 - 16
Energy (at each range) in Joules: 2000
Single Impulse: Yes
Selectable auto frequency per minute: 40/20/10
ARC module: Yes
DC Test Mode: Yes
Voltage range in kV: 0 - 20
Current in mA: 20
Burn Current in mA (Optional): 200 @ 5kV; 100 @ 10Kv; 50 @ 20Kv
Sheath Test (Optional): Yes
Voltage in kV: 0 - 8
Current in mA: 50
Prelocator:
Maximum measuring range (KM ): 160
Prelocation modes: TDR , ICM , SIM/MIM , Decay
Resolution: 0.4m
Sampling rate: 400MHz
Pulse Width: 20ns - 10µs
Pulse Amplitude: 65V
VOP (V) m / µs: 20 - 300
Output Impedance: 5 - 100 ohms
Input signal gain in dB: 0 - 100
Display: Colour Tablet - 10 inch - Touch
No of records storage memory: > 1000
Communication interface: USB
Control: Touch
Internal battery: Li-ion - 7.4V/6000 mAh
Battery operation fully charged: 8 hrs
Battery charger : 110 - 220V AC - 50Hz , 8.4V/3A DC
General Parameters :
Input Power Supply: 230V AC ± 10%
Power Frequency: 50Hz or 60Hz ± 5%
Operating temperature: -10°C to +55°C
IP rating : 21
Impulse: 4kV/1000J (Optional) only applicable for COMPAC 40 and 40D & Not Applicable for Compac 20 and 20D
Approximate Weight in KG: 190
Approximate size (LxWxH): 600 X 600 X 1000 mm
Standard Accessories
50kV High Voltage cable in meter
10 Meter for HV, Mains and Earth Meter.
Mains cable in meter
Earth cable in meter
Rexin cover
