Monolithic Power Systems (MPS) MPQ4475GR-E-AEC1-Z Switching Voltage Regulators 36V,2.5A,Frequency Selectable,Step-Down Converter with Single USB Charging Port AEC-Q100 Qualified
ModelMPQ4475GR-E-AEC1-Z
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Shutdown: Shutdown
Topology: Buck
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Output Current: 2.5 A
Output Voltage: 5 V
Load Regulation: 1 %
Number of Outputs: 1 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 7 V
Switching Frequency: 350 kHz
Supply Voltage - Min: 7 V
Operating Supply Current: 1.6 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
