Monolithic Power Systems (MPS) MPM81204GBC-T Power Modules 4V to 16V Input, Quad-Output Power Module with dual 12A and dual 5A outputs

Dimensions: 9.5 mm x 16 mm x 4.98 mm

Output Current: 5 A, 12 A

Output Voltage: 600 mV to 3.3 V, 600 mV to 5.5 V

Load Regulation: 0.5 %

Moisture Sensitive: Yes

Input Voltage - Max: 16 V

Input Voltage - Min: 4 V

Switching Frequency: 600 kHz, 800 kHz, 1 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
