Pitch: 1.25 mm (0.049 in)
Application: Wire-to-Board, Signal
Unit Weight: 198.698 mg
Housing Color: Natural
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Right Angle
Mounting Style: SMD/SMT
Number of Rows: 1 Row
Voltage Rating: 125 VAC/DC
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Polyamide (PA)
Termination Style: Solder
Mating Post Length: 3.4 mm (0.134 in)
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Insulation Resistance: 100 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
