Pitch: 4.2 mm (0.165 in)
Application: Board-to-Board, Wire-to-Board, Power
Row Spacing: 4.2 mm (0.165 in)
Unit Weight: 3.691 g
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 600 VAC/DC
Contact Plating: Nickel
Contact Material: Brass
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 10 Position
Termination Post Length: 4.46 mm (0.176 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
