Color: Green
Pitch: 5.08 mm
Height: 16 mm
Length: 22.9 mm
Unit Weight: 5.444 g
Current Rating: 18 A
Mounting Angle: 45 deg
Mounting Style: PCB Mount
Voltage Rating: 300 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 26 AWG
Contact Plating: Tin
Contact Material: Tin
Housing Material: Polyamide (PA)
Connection Method: Lever
Termination Style: Through Hole
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
