Color: Gray
Pitch: 12 mm
Width: 29.8 mm
Height: 43 mm
Length: 49 mm
Unit Weight: 60.264 g
Current Rating: 150 A
Mounting Style: DIN Rail (35)
Number of Rows: 2 Row
Voltage Rating: 600 V
Wire Gauge Max: 1/0 AWG
Wire Gauge Min: 6 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 6 AWG to 1/0 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
