Pitch: 3.5 mm (0.138 in)
Application: Wire-to-Board, Power
Row Spacing: 4.6 mm (0.181 in)
Unit Weight: 2 g
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 11 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 400 VAC/DC
Contact Plating: Gold
Contact Material: Tin
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Termination Post Length: 3.2 mm (0.126 in)
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
