Pitch: 2.54 mm (0.1 in)
Application: Wire-to-Board, Wire-to-Wire, Power, Signal
Unit Weight: 222 mg
Housing Color: Black
Latching Type: Friction Lock
Contact Gender: Pin (Male)
Current Rating: 4 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 500 V
Contact Plating: Tin
Contact Material: Brass
Housing Material: Nylon
Termination Style: Solder Pin
Mating Post Length: 7.49 mm (0.295 in)
Flammability Rating: UL 94 V-1
Number of Positions: 2 Position
Termination Post Length: 3.56 mm (0.14 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
