Pitch: 2.54 mm (0.1 in)
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 1.175 g
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 250 V
Contact Plating: Gold
Contact Material: Tin
Housing Material: Polyester
Termination Style: Solder Pin
Mating Post Length: 6.1 mm (0.24 in)
Flammability Rating: UL 94 V-0
Number of Positions: 14 Position
Termination Post Length: 2.79 mm (0.11 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
