Display: 320 x 240 color QVGA TFT LCD with back lighting.
Display Range: 1.0 x 10-11 - 20,000 Torr
1.0 x 10-11 - 2.7 x 10+4 mbar
1.0 x 10-9 - 2.7 x 10+6 Pascal
1.0 x 10-8 - 2.0 x 10+7 microns
Front Panel Controls: Power on-off switch, setup and operational commands can be accessed via the keypad
Units: User Selectable
Region: United States
Electrical Plug: United States
Power Requirements: 150 watts maximum, 100 - 240 VAC 50/60 Hz
Interface: RS232 and RS485
Relays: 12
Set Point Contact Rating: 2 Amps @ 30 VAC
Operating Temperature: 5 - 40° C (41 - 104°F)
Storage Temperature: -10 - 55°C (14 - 131°F)
Relative Humidity: 80% max for temperatures less than 31°C, decreasing linearly to 50% maximum at 40°C
Leak Test: Relative logarithmic bar graph display and variable rate audio signal
Weight: 8 lbs (3.6 kg)
Compliance: CE
