MKS 631F Heated Absolute Baratron® Capacitance Manometer (150°C; 10 Torr)

Measurement Type: Absolute

Full Scale Range: 10 Torr

Sensor Temperature: 150°C

Accuracy: 0.50% of Reading

Fitting Type: 8 VCR female

Analog Output: 0-10 VDC

Analog Connector: 15-pin D-sub

Trip Relays: 2

Relay Contact Rating: 0.20 amps @ 30 VDC

Resolution: 0.01% of Full Scale

Zero Temperature Coefficient: 0.004% of Full Scale/°C (0.008% of Full Scale/°C for 1 Torr range)

Span Temperature Coefficient: 0.02% of Reading/°C

Response Time: 50 msec

Warm-up Time: 4 hours or less

Internal Volume: 6.3 cc

Operating Temperature Range: 15-50°C

Overpressure Limit: 45 psia

Exposed Materials: Inconel® or Incoloy® nickel alloys

Power Requirements: ± 15VDC (±5%) @ 1.0 amps max

Ambient Airflow Requirements: 50 ft/min for ambient temperatures of 45 - 50°C

Compliance: CE

For specific range please check the attachment below!
