Measuring range:
X-axis 500mm
Y-axis 700mm
Z-axis 450mm
Measurement method: Ultrahigh-precision linear encoder
Maximum measuring speed: 200mm/s
Maximum acceleration: 980mm/s2
Resolution: 0.00001mm
Guide method: Air bearing
Measuring table
- Material: Cast iron
- Size: 550×750mm
- Tapped insert: M8×1.25mm (for workpiece clamping)
Table loading
- Maximum workpiece height: 695mm
- Maximum Table loading: 250kg
Mass (main unit): 3500kg
Air supply
- Pressure: 0.5 MPa
- Consumption: 120L/min under normal conditions (air source: 160L/min or more)
