Measuring Range(μm )
Ra,Rq: 0.05~10.0
Rz,Rt: 0.1~50
Parameter(μm): Ra,Rz,Rq,Rt
Travel Length(mm): 5.6
Sample Length(mm): 0.25,0.80,2.50
Evaluation Length(mm): 1.25,4.0
Display Error: ±10%
Display Variability: <12%
Stylus Radius and Angle: 90°(+5°,-10°)
Stylus Radius: 10μm±1 μm
Measuring Force of Probe: ≤0.016N
Force Change Rate: ≤800N/m
Sensor Guide Pressure: ≤0.5N
Battery: One 1.5V AA Dry Battery
Dimensions: 73mm×28mm×62mm
Net Weight: 220g
Working Environment Conditions
Temperature: -20°C~40°C
Relative Humidity: < 90%
No Vibration And Corrosive Medium Around
Standard Delivery
Main Unit: 1 pc
Calibration Block: 1 pc
Instrument Case: 1 pc
Screwdriver: 1 pc
Optional Delivery
Bluetooth Adapter: SRT-BA
