Probe Type: N
Measuring Range: 0~1500μm
Working Principle: Eddy
Resolution: 0.1μm
Accuracy:
Zero-pointCalibration: ±(2%H+1)μm
Two-point Calibration: ±[(1~2)%H+1]μm
Test Conditions:
Minimum radius of curvature: Convex 3mm
Minimum area diameter: Φ5mm
Matrix critical thickness: 0.3mm
Temperature: 0 °C~40 °C
Humidity: 20% Rh~90% Rh
No Strong Magnetic Field Environment
Power Supply: 2*AA Alkaline batteries
Weight: About 240g
Dimensions: 151×76×38mm
Standard Delivery
Main Unit: 1 pc
Iron Plate or Aluminum Plate: 1 pc
Calibration Foils: 5 pcs
Package Case: 1 pc
No.5 Alkaline Battery (1.5V): 2 pcs
Probe: optional
