Fall Time: 20 ns
Rise Time: 35 ns
Technology: SiC
Mounting Style: Screw Mount
Transistor Polarity: N-Channel
Vf - Forward Voltage: 1.5 V at 100 A
Vr - Reverse Voltage: 700 V
Pd - Power Dissipation: 674 W
Vgs - Gate-Source Voltage: - 10 V, + 25 V
Typical Turn-On Delay Time: 40 ns
Typical Turn-Off Delay Time: 50 ns
Id - Continuous Drain Current: 238 A
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 9.5 mOhms
Vds - Drain-Source Breakdown Voltage: 700 V
Vgs th - Gate-Source Threshold Voltage: 1.9 V
