Width: 1.6 mm
Height: 1.3 mm
Length: 2.9 mm
Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Amplifier Type: Zero-Drift Op Amp
Mounting Style: SMD/SMT
SR - Slew Rate: 9.5 V/us
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.4 V
Ib - Input Bias Current: 2 pA
Operating Supply Current: 2 mA
Operating Supply Voltage: 2.4 V to 5.5 V
Ios - Input Offset Current: 400 pA
Output Current per Channel: 30 mA
Vos - Input Offset Voltage: 25 uV
GBP - Gain Bandwidth Product: 10 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 6 fA/sqrt Hz
en - Input Voltage Noise Density: 11 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 140 dB
PSRR - Power Supply Rejection Ratio: 137 dB
