Technology: CMOS
Output Type: Push-Pull
Supply Type: Single
Unit Weight: 6.300 mg
Qualification: AEC-Q100
Response Time: 56 ns
Mounting Style: SMD/SMT
Comparator Type: General Purpose
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Propagation Delay Time: 56 ns
Ib - Input Bias Current: 1 pA
Operating Supply Current: 100 uA
Operating Supply Voltage: 3 V, 5 V
Output Current per Channel: 30 mA
Vos - Input Offset Voltage: 10 mV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
CMRR - Common Mode Rejection Ratio: 66 dB
PSRR - Power Supply Rejection Ratio: 70 dB
