Microchip Technology BM83SM1-00TB USB Adapter Bluetooth Audio Class 1 Transceiver Module with A2DP Source

Core: DSP

Class: Class 1, Class 2

Width: 15 mm

Height: 2.5 mm

Length: 32 mm

Antenna: PCB Antenna

Protocol: Bluetooth 5.0

Data Rate: 3 Mb/s

Frequency: 2.44 GHz

Shielding: Shielded

Dimensions: 32 mm x 15 mm x 2.5 mm

Output Power: 11 dBm

Interface Type: GPIO, I2C, SPI, UART, USB

Mounting Style: SMD/SMT

Frequency Range: 2.402 GHz to 2.48 GHz

Moisture Sensitive: Yes

Modulation Technique: DPSK, DQSK, GFSK

Receiver Sensitivity: - 90 dBm

Supply Voltage - Max: 4.2 V

Supply Voltage - Min: 3.2 V

Operating Supply Voltage: 3.3 V

Supply Current Receiving: 49 mA

Supply Current Transmitting: 59 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
