Width: 6 mm
Height: 1.6 mm
Length: 8 mm
Antenna: External
Protocol: BLE, Bluetooth 5.0
Frequency: 2.44 GHz
Dimensions: 6 mm x 8 mm x 1.6 mm
Memory Size: 24 kB, 32 kB, 256 kB
Sensitivity: - 90 dBm
Unit Weight: 5.358 g
Output Power: 0 dBm
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Receiver Sensitivity: - 90 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.9 V
Antenna Connector Type: RF Pad
Operating Supply Voltage: 1.9 V to 3.6 V
Supply Current Receiving: 3.2 mA
Supply Current Transmitting: 3.3 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
