Microchip Technology ATZB-RF-233-1-CR Zigbee Modules ZigBit Amp RF233

Range: 1.96 km

Data Rate: 2 Mb/s

Frequency: 2.4 GHz

Dimensions: 25 mm x 20 mm

Sensitivity: - 104 dBm

Unit Weight: 4.005 g

Output Power: 20.5 dBm

Interface Type: SPI

Moisture Sensitive: Yes

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 2 V

Antenna Connector Type: Chip

Operating Supply Voltage: 3 V

Supply Current Receiving: 7.5 mA

Supply Current Transmitting: 157 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4, Zigbee
