Fall Time: 60 ns
Rise Time: 75 ns
Technology: Si
Unit Weight: 10 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Qg - Gate Charge: 280 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.04 kW
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 65 ns
Typical Turn-Off Delay Time: 190 ns
Id - Continuous Drain Current: 60 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 55 S
Rds On - Drain-Source Resistance: 110 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 4 V
