Fall Time: 26 ns
Rise Time: 29 ns
Technology: Si
Unit Weight: 6.200 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 120 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 500 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 28 ns
Typical Turn-Off Delay Time: 95 ns
Id - Continuous Drain Current: 14 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 16 S
Rds On - Drain-Source Resistance: 820 mOhms
Vds - Drain-Source Breakdown Voltage: 1 kV
Vgs th - Gate-Source Threshold Voltage: 2.5 V
