Wind Speed
Operating Range: 0~60m/s (0~134mph)
Accuracy: ±0.5m/s (1.1mph) or 5% (whichever is greater)
Resolution: 0.1m/s
Threshold: <0.2m/s Response Time: 1s
Wind Direction
Range: 0~360º
Accuracy: ±5° (Including compass error of ±2°)
Resolution: 1º
Threshold: <0.2m/s
Response Time: 1s
Electrical
Measurement format: Two orthogonal axes, North/South and East/West
Measurement rate: 1Hz
Operating frequency: 40Hz
Signal Output:
- Digital: RS-232, 50ft, RS-485, 4000ft
- Analog: 0~1VDC
Power requirement: Sensor: 8~36VDC , 40mA at 12VDC
Mean Time Between Failures (MTBF): 80000 hours
Environmental
Temperature: 40~60°C (-40~140°F)
Humidity: 0~100%
Physical
Weight: 1.16kg (2.55lbs)
Size: 228 mm (9.0 in) high by 152 mm (6.0 in) diameter
Mounting: ¾ in IPS (1.05” or 26 mm OD) vertical pipe stub
