Punching
- Rated capacity: 45 T
- Maximum capacity: 22 x 15 mm
- Diameterxthickness: 38 x 8 mm
- Stroke length: 50 mm
- Speed - 20 mm travel: 20 cycles/min
- Throat size (standard): 175 mm
- Deep throat: 210mm
- Largest hole (optional): 110 mm
- Max. Section flange punch: 102mm
- Working height: 940 mm
Shearing
- Flat Bar - max. thickness: 200 x 15 mm
- Flat bar - max. width: 300 x 12 mm
- Angle Iron trim: 80 x 10 mm
- Working height: 940 mm
Angle Cutting
- 90° cut: 100 x 10 mm
- 45° Mitre cut: 70 x 6 mm
- Working height: 1140 mm
Section Cutting
- Round / Square bar: 30/30 mm
- Channel / Beam (optional): 80 x 45 mm
- Tee (optional): 40 x 7 mm
- Working height: 1135 mm
Notching
- Material thickness: 8 mm
- Width: 35 mm
- Depth vee (optional) / Rectangular: 60/75 mm
- Angle flange: 80 x 8 mm
- Working height: 940 mm
Techinical
- Motor: 5 Hp
- Net weight / Gross weight: 1100/1200 kg
- Machine dimension: 145 x 59 x 162 cm
- Packing dimension: 153 x 77 x 182 cm
