Type of battery pack: Li-ion
Battery voltage: 18 V
Battery pack capacity: 3 x 2 Ah
Maximum torque - soft: 25 Nm / 221.3 in-lbs
Maximum torque, hard: 50 Nm / 442.5 in-lbs
Adjustable torque: 1.5 - 6 Nm // 13.3 - 53.1 ft. lbs
Ø Drill masonry: 10 mm / 3/8 "
Ø Drill steel: 10 mm / 3/8 "
Ø Drill soft wood: 20 mm / 25/32 "
No-load speed: 450 / 1800 rpm
Maximum impact rate: 27000 bpm
Chuck capacity: 1.5 - 13 mm // 1/16 - 1/2 "
Weight (including battery pack): 1.6 kg / 3.5 lbs
Vibration
Drilling in metal: 2.8 m/s²
Uncertainty of measurement K: 1.5 m/s²
Impact drilling concrete: 21.5 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission
Sound pressure level: 89 dB(A)
Sound power level (LwA): 100 dB(A)
Uncertainty of measurement K: 3 dB(A)
Delivery
Keyless chuck
2 x Charger SC 30
Plastic carry case
Belt hook and bit case
3 x Li-Power battery packs (18 V/2.0 Ah)
Accessories
SCREWDRIVING/FIXING
Screwdriving bits, Screwdriving bit sets, Bit holders, Accessories for impact drivers & wrenches, Other accesssories screwdriving/fixing
Datasheet
Features
Powerful, compact hammer drill with extremely compact design
Hammer drill function for drilling in masonry
Integrated LED work light with night light function for optimal brightness in the work area
With handy belt hook and bit case which can be fixed either on the right or left side
Battery packs with capacity display for checking the charge status
Ultra-M technology: highest performance, gentle charging and 3 years of warranty on the battery pack.
