Flow Ranges: 15-1500 sL/min at 45 PSIA
Uncertainty: ±0.45% of reading
Weight: 90 lbs / 41 kg
Dimensions (H x W x D): 32W” x 34H” x 12D”
Data Cable: 1 meter, for use with data port
Data Port: RS-232 (serial), for PC interface
Display: Graphical LCD with backlight
Flow Measurement Cell: Integrated (all-in-one design)
Flow Measurement Style: Single, Continuous or Burst, with averaging function user-selectable from 1 to 100
Flow Measurement Type: Volumetric (primary by nature), Standardized
Gas Compatibility: Noncorrosive, noncondensing, noncombustible gases, less than 70% humidity
Humidity (Ambient): 0-70%, noncondensing
Inlet and Outlet Fittings: 1 1/2” Swagelok® compression tube fitting
Overpressure Release Fitting: 1/2” Swagelok® compression tube fitting
Storage Temperature: 0-70° C
Power: External power module
Input: 100-240 VAC, 1.6A (max), 50-60 Hz
Output: 12 VDC, 3.0A
Pressure (Operating Range): 14-45 PSIA
Pressure Transducer: 0-50 PSI (absolute), accuracy ±0.05% FS (typical), ±0.10% (max)
Purge Fittings: 1/4” Swagelok® compression tube fittings
RoHS Compliant: Yes
Temperature (Operating): 15-30° C
Pneumatic Valve Operation: Air supply: 80-100 PSI (not provided)
Fitting: 1/4th” Swagelok® compression
Warranty: 1 year
