MEMMERT UN160pa Paraffin oven (161 litres, 1600W, twin display)

Volume: 161 liters

Interrior dimensions: 560W x 720H x 400D mm

Exterior dimensions: 745W x 1104H x 584D mm

Stainless steel grids (standard): 2

Max. number of grids: 8

Setting temperature range: 20℃ to 80℃

Working temperature range: at least 5 above ambient temperature to 80℃

Setting accuracy: 0.1℃

2 Pt100 sensors DIN class A in a 4-wire circuit for mutual monitoring, taking overfunctions in case of an error

ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour display.

Language setting: German, English, Spanish, French, Polish, Czech, Hungarian

Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days

Function HeatBALANCE adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 %

Function setpointWAIT: the process time dose not start until the set temperature is reached

Calibration: three freely selectable temperature values

Adjustable parameters: temperature (Celsius or Fahrenheit), programme time, time zones

Convection: natural convection

Programme stored in case of power failure

Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port

Ethernet interface on the rear of the appliance for reading out the protocol log and for uploading programmes and for online logging

Temperature control: mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature, overtemperature monitor TWW, protection class 3.1 or adjustable temperature limiter TWB, protection class 2, selectable on display

Additionally integrated over- and undertemperature monitor "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature

Autodiagnostic system: for fault analysis

Alarm: visual and acoustic

Door: fully insulated stainless steel door with 2-point locking

Structured stainless steel housing, scratch-resistant, robust and durable; rear of zinc-plated steel

Internal data logger with a storage capacity of at least 10 years

Voltage: 230 V, 50/60 Hz

Electrical load: 1600 W

Ambient temperature: 5 – 40℃

Humidity: max. 80% rh, non-condensing
