Display: 4.3-inch high-definition LCD touch screen
Reading digits: 4 and a half positions
Measurement range: 1μΩ~2MΩ
Resistance range: 20mΩ / 200mΩ / 2Ω / 20Ω / 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ
Basic measurement accuracy: 0.05% (refer to the user manual for detailed information)
Resistance measurement time: fast: 20ms, slow: 40ms
Temperature measurement time: 100 ± 10ms
Test end configuration: four terminals
Low voltage measurement: open circuit voltage ≤ 40mV, effective range: 2Ω, 20Ω, 200Ω, 2kΩ
Statistical functions: Qualified and unqualified
Save measurement settings parameters: 10 sets
Temperature measurement: sensor: PT1000 -200.0℃~300℃; display: -99.9℃~999.9℃
Other functions: include temperature compensation and temperature conversion
Comparator – Signal output: HI/IN/LO
Comparator – Sound: Call mode: OFF, IN, HI/LO
Comparator – Limit setting mode: 3, absolute value upper/lower limit
Interface configuration: standard: RS232, Handler (RS485 optional)
Standard accessory: power cord, four terminal low resistance test line, PT1000 thermistor
