MEAN WELL SKMW15G-05 Isolated 18-75Vin 5V 3A 15W DIP 1x1 Iso Reg

Width: 25.4 mm (1 in)

Height: 10.2 mm (0.402 in)

Length: 25.4 mm (1 in)

Industry: Industrial

Dimensions: 25.4 mm x 25.4 mm x 10.2 mm

Application: Telecom/Datacom System, Wireless Network, Industrial Control, Instrument, Analyzer, Detector, Data Switch

Unit Weight: 20 g

Output Power: 15 W

Input Voltage: 18 VDC to 75 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 3 A

Output Voltage-Channel 1: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
